In scenarios such as municipal roads, large construction sites, and mining areas, dust control has always been a key focus of environmental protection efforts. Traditional water trucks can moisten the ground to suppress dust, but they often fall short when dealing with dust from high-altitude work areas or large-scale dust. However, the innovative combination of a 60-meter mist cannon machine and a water truck, with its dual collaborative model of "ground moistening + high-altitude dust suppression", breaks the limitations of single-equipment dust reduction and provides a more efficient and precise dust control solution for complex scenarios.

Shortcomings of Traditional Dust Reduction and Breakthroughs of the Matching Scheme

When a water truck operates alone, the water flow directly washes the ground, which can temporarily suppress ground dust but cannot reach dust generated at high places such as construction tower crane work areas and the top of material piles. At the same time, excessive watering can make the road muddy, affecting traffic, and especially in winter, it is prone to safety hazards such as road icing. Simply using a mist cannon machine, although it can cover high-altitude dust, cannot solve the problem of secondary lifting of ground dust.

The matching scheme of the 60-meter mist cannon machine and the water truck just makes up for this defect. The water truck is responsible for precise watering of roads and material yard grounds, firmly locking the ground dust; the mist cannon machine, with its 60-meter ultra-long range, directionally suppresses high-altitude dust and dust fog rising from the top of material piles. Together, they form a three-dimensional dust reduction network from "ground to high altitude", increasing dust reduction efficiency by more than 60% compared with single equipment.

Core Advantages of the Matching Equipment

Flexible Collaboration for Precise Dust Control

The 60-meter mist cannon machine adopts a rotatable barrel design, which can achieve 360-degree full rotation, and the pitch angle can be adjusted between -10 degrees and 60 degrees, accurately targeting dust points at different heights. The water truck is equipped with high-pressure water guns and wide-range sprinkler heads, which can adjust the water volume according to road width and dust level. The two realize linked operation through wireless remote control. When the water truck is moving, the mist cannon machine synchronously sprays and suppresses dust in areas such as green belts on both sides of the road and above construction enclosures, forming a dust reduction closed loop without dead angles.

Efficient, Energy-Saving and Strongly Adaptive

This matching combination adopts an intelligent control system, which can automatically adjust the spray volume of the mist cannon machine and the water volume of the water truck according to dust concentration. The atomized particle diameter of the mist cannon machine can be controlled between 50-150 microns, which has a large contact area with dust, significant dust suppression effect, and water consumption is only 30% of that of traditional water trucks. At the same time, the mist cannon machine can directly use water from the water truck's tank without additional water supply pipelines, enabling flexible operation in construction sites, mining areas and other scenarios without fixed water sources.

Scene Adaptation and Full-Area Coverage

Whether it is municipal road cleaning or large construction site construction, this matching combination can play an excellent role. In road cleaning, the water truck first moistens the road surface, and the mist cannon machine follows to suppress secondary dust generated by vehicle driving; in construction site operations, the water truck sprinkles water to keep the material yard ground moist, and the mist cannon machine sprays fixed-point mist on key dust sources such as mixers and tower crane work areas, achieving precise adaptation to different scenarios.

Case: Dust Reduction Upgrade Practice on Municipal Roads

A high-tech zone in a city once faced severe road dust problems. There were more than 10 ongoing construction sites in the area, with frequent movement of large trucks. The road dust concentration often exceeded 0.8mg/m³, leading to continuous complaints from surrounding residents. Previously, 8 water trucks were used for dust reduction operations, sprinkling water 12 times a day. Not only was water consumption high, but the roads were often muddy, and the dust reduction effect was unsatisfactory.

Last year, the local municipal department introduced 5 sets of 60-meter mist cannon machines matched with water trucks. During operation, the water truck travels at a speed of 20 km/h, sprinkling water on the road surface with a wetting depth of 3 cm; the mist cannon machine turns on the 60-meter range mode to spray and suppress dust within 5 meters high on both sides of the road. For key areas such as construction site entrances and exits, they can also stop working: the water truck focuses on 冲洗 the ground, and the mist cannon machine sprays remotely on the material piles in the construction site.

One month after operation, monitoring data showed that the road dust concentration in the area dropped to 0.3mg/m³, meeting the national first-class standard. Feedback from surrounding residents indicated that road muddiness had significantly improved, and air freshness had noticeably increased. More importantly, the total daily water consumption of the matched equipment was 40% less than before, vehicle fuel consumption was reduced by 25%, and the comprehensive operating cost decreased by 30%, achieving a dual improvement in dust reduction effect and economic benefits.

Multiple Values of the Matching Scheme

In addition to efficient dust reduction, the combination of the 60-meter mist cannon machine and the water truck has multiple practical values. During high-temperature periods in summer, the mist cannon machine can spray cool water mist, cooperating with the water truck to cool the road surface and create a comfortable micro-environment for urban roads. During periods of poor air quality, their collaborative operation can quickly reduce PM2.5 concentration in the air and improve regional air quality.

For construction enterprises, this matching scheme can help them easily meet environmental protection requirements and reduce the risk of work suspension and rectification due to excessive dust. In mining operations, the matched equipment can move with mining vehicles to conduct real-time dust reduction on mining faces and transportation roads, protecting the health of miners and extending the service life of equipment.

In today's increasingly strict environmental protection requirements, the dust reduction capability of single equipment can no longer meet the needs of complex scenarios. The combination of the 60-meter mist cannon machine and the water truck, with its collaborative and efficient dust reduction mode, provides a comprehensive solution for various dust control scenarios. As the water truck leaves a moist track on the road and the mist cannon machine weaves a dust suppression curtain in the air, a ecological picture of "clean ground and fresh air" is gradually unfolding.
