Instruction Manual for Automatic Mist Cannon Machine The automatic mist cannon machine combines high-pressure water flow with high-speed air flow to atomize water into fine mist particles. It then uses wind power to transport the mist droplets to designated areas over long distances, achieving rapid and effective dust suppression. Many people are unaware of the correct usage of automatic mist cannon machines. Below, the editor from Zhengtong Mist Cannon compiles a detailed instruction manual for automatic mist cannon machines, hoping to help you!
1. Structure and Principle
The automatic mist cannon machine mainly consists of the following parts:
Base: Provides stable support.
High-pressure Water Pump: Generates high-pressure water flow to provide power for atomization.
Stainless Steel Fan: Produces high-speed air flow to break water droplets into fine mist particles and transport them over long distances.
Nozzles: Atomize water into fine mist droplets.
PLC Distribution Box: Controls the equipment's start, stop, spray volume adjustment, etc.
IoT System (Optional): Enables intelligent spraying operations and automatically adjusts spray volume based on dust levels.
2. Usage Steps
Preparation Work
Ensure the mist cannon machine has sufficient water supply and the water source pipeline is properly connected.
Check the power cord to ensure the power supply is connected and functioning normally.
Check if all connections are accurately aligned and if fasteners are secure.
Starting the Equipment
Turn on the power switch to start the mist cannon machine.
Press the start button to begin water supply and compressed air supply.
Adjusting Spray Range and Wind Direction
Based on actual needs, adjust the spray range and wind direction of the mist cannon machine via the control panel or remote control.
Operating the Equipment
Observe the spraying situation and adjust the spray volume and range as needed.
Control the equipment's working time and frequency to ensure the expected dust suppression effect is achieved.
Shutting Down the Equipment
After use, first close the water supply pipeline.
Stop the operation of the mist cannon machine and turn off the power switch.
Clean and maintain the equipment, then place it in an appropriate storage location.
3. Maintenance
Regular Inspection
Regularly check if all connections are loose and if fasteners are secure.
Check if nozzles are clogged; clean them promptly if clogging occurs.
Oil Replacement
The oil in the pump head and crankcase should be replaced regularly. Replace it for the first time after 20 hours of initial use, and then every 50 hours of use thereafter.
Equipment Cleaning
Regularly clean the surface and interior of the equipment to remove dust and impurities.
Clean the filter screen and filter cap to keep them unobstructed.
4. Common Faults and Troubleshooting Methods
No mist sprayed, only water dripping: The filter screen or nozzle may be clogged. Remove the filter screen or nozzle and clean the clogging material.
Sprayed mist is scattered and not conical: The nozzle orifice shape may be irregular or blocked by dirt. Unscrew the nozzle cap to adjust and clean the orifice.
Air cylinder cover or water filling cover leaks air: Check if the rubber gasket is intact, properly placed, and if the flange is firmly welded. Replace the gasket or adjust the installation position promptly if damaged or misaligned.
Switch leaks water: The switch may be damaged or the asbestos rope under the switch cap may be aged and have gaps. Replace the switch or asbestos rope and tighten relevant components.
When operating the automatic mist cannon machine, always pay attention to safety: avoid spraying directly at personnel, and avoid spraying against the wind to prevent pollution spread. Clean and maintain the equipment regularly to keep it in normal operating condition.
